Sanitary Digital Thermometer/Transmitter

The Reotemp Sanitary Digital Thermometer/Transmitter is a durable, high-accuracy digital thermometer designed for food, beverage, brewing, and pharmaceutical applications. Built with 316 stainless steel construction and a 3-A approved sanitary Tri-Clamp® connection, this thermometer ensures precise temperature measurement in hygienic environments. It features an IP67/NEMA 4X-rated enclosure, a 5-year battery life, and an optional 4-20mA transmitter output for seamless integration into process control systems.

Key Features

3-A Conformance Certificate Included: Certified for sanitary applications in food, beverage, and pharmaceutical industries.
High-Accuracy 1000Ω RTD (Class A): Provides precise and repeatable temperature readings.
IP67/NEMA 4X Water-Resistant Enclosure: Fully sealed for washdown environments and harsh conditions.
Long Battery Life: 5-year battery-powered operation (4-20mA models are loop-powered 9-36VDC).
4-20mA Output Option: Enables seamless integration with industrial process control systems.
Wide Temperature Range: Measures from -328°F to 1112°F (-200°C to 600°C) for various applications.
Large 4-Digit LCD Display: Easy-to-read 1/2” height display with programmable refresh rate.

Industries

Food, Beverage, Dairy, Brewing, Wine, Personal Care

Available Options

Process Connection Sizes: Available in ¾”, 1.5”, 2”, 2.5”, 3”, and 4” Tri-Clamp® sizes.
Custom Stem Lengths: Choose from 2.5” to 36” standard lengths, or customize to fit your needs.
Calibration Certifications: 1-point or 3-point NIST-traceable calibration certificates available.
Custom Logo & Stainless Steel Tagging: Personalization for traceability and compliance.
Lens Material Options: Choose between polycarbonate plastic (standard) or glass for added durability.

Why Choose Reotemp’s Sanitary Digital Thermometer?

Optimized for Clean-in-Place (CIP) Systems: Tri-Clamp® sanitary connection ensures easy installation and removal.
Reliable & Long-Lasting Performance: Durable 316 stainless steel construction withstands washdowns and cleaning agents.
Highly Accurate & Stable Readings: Precision Class A RTD sensor provides reliable temperature monitoring.
Flexible Configuration Options: Available in multiple Tri-Clamp® sizes, stem lengths, and optional transmitters.
Seamless Industrial Connectivity: Optional 4-20mA output (loop-powered) allows integration with SCADA and PLC systems.
